TFT
Your Current Location :Home » Product » TFT  » TFT

TFT

市 场 价:¥0

优 惠 价:¥1

库  存:999

Panel include TN, IPS and wide viewing technology.
Interface are available of RGB, LVDS, SPI, MIPI, MCU etc.
High brightness and transflective, Sunlight readable.
Customized design of FPC, back light, Touchscreen, bezel, PCB, interface and etc.
TFT module plus include driving PCB board, RTP/CTP assembly, OCA Full Bonding.
Quality control: Equipment support: Brightness photometer or illuminometer(BM-7), Color analyzer (CA310)
Product from 0.83inch to 12.1inch, be widely used in automotive, home appliance, medical instrument, industrial equipment and communication devices.

选择商品:
1

商品详细


  • Part No. Size Resolution Outline(mm) AA size(mm) View angle
    (U/D/L/R)
    Contrast Interface Operating
    Temp
    (℃)
    Storage
    Temp
    (℃)
    Controller Brightness Touch Panel Download
    JT144MGPSV01 1.44” 128x128 33.00x36.00 25.84x26.496 6 O'clock 500:1 8-bit parallel -20~70 -30~ 80 ST7735S 150 N
    JT144MGPSV02 1.44” 128x128 28.80x35.09 25.5x26.5 6 O'clock 500:1 MCU parallel -20~70 -30~80 ST7735S 150 N
    JT44MZGSV02 1.44” 128x128 32.36x38.00 25.5x26.5 6 O'clock 500:1 3/4 line SPI -20~70 -30~ 80 ST7735S 240 N
